OTR Grader Tyre G2/L2 | |||||||||
Size | P.R. | Overall Diameter (mm) | Section Width (mm) | Rim | Max Load (kgs) | Inflation Pressure (Kpa) | Tread Depth (mm) | ||
10 km/h | 50 km/h | 10 km/h | 50 km/h | ||||||
1300-24 TG | 16 | 1280 | 330 | 8.00TG | 6500 | 3300 | 600 | 450 | 24 |
1400-24 TG | 16 | 1350 | 360 | 8.00TG | 7300 | 3650 | 550 | 375 | 25 |
15.5-25 | 16 | 1275 | 395 | 12.00/1.3 | 6750 | 3850 | 525 | 325 | 25 |
16.00-24 | 20 | 1460 | 425 | 10.00AV | 9400 | 5350 | 525 | 425 | 29 |
17.5-25 | 20 | 1350 | 445 | 14.00/1.5 | 8250 | 5000 | 575 | 400 | 26 |
20.5-25 | 20 | 1490 | 520 | 17.00/2.0 | 9500 | 6000 | 450 | 325 | 29 |
23.5-25 | 20 | 1615 | 595 | 19.50/2.5 | 10900 | 5450 | 375 | 250 | 31 |
