| Model | TP80 | TP120 | TP160 | T200 | |
| Load Capacity | T | 80 | 120 | 160 | 200 |
| Max Tyre Dimension | inch | 15 | 20 | 20 | 20 |
| The diameter of piston | mm | 200 | 250 | 250 | 280 |
| The diameter of piston rod | mm | 110 | 180 | 180 | 180 |
| Cylinder Stroke | mm | 400 | 400 | 400 | 400 |
| Operating Pressure | MPa | 21 | 25 | 32 | 32 |
| Oil Tank Capactiy | L | 30 | 50 | 50 | 60 |
| Motor | Kw | 5.5 | 7.5 | 7.5 | 11 |
| Sies(L*W*H) | mm | 1640*700*2170 | 2080*850*2200 | 2080*850*2200 | 2100*930*2153 |
| Packing size(L*W*H) | mm | 1700*800*2170 | 2150*950*2200 | 2150*950*2200 | 2200*1000*2170 |
| Weight | Kg | 1100 | 1650 | 1650 | 1900 |
